This TMC replacement Motor / macerator pump works at 12 volts. Designed to fit on all TMC electric toilets, Jabsco, Raritan PH/Compact, Wilcox Crittenden "Head Mate", Groco HC, SeaLand 750 Series, or PAR 29090/29120 Series. The motor is used specifically on automatic marine toilets.
A stainless steel, corrosion resistant shaft drives the built-in self-priming flexible impeller flush pump to offer a vertical lift of up to 25".
SPECIFICATIONS:
A stainless steel, corrosion resistant shaft drives the built-in self-priming flexible impeller flush pump to offer a vertical lift of up to 25".
SPECIFICATIONS:
- Motor: 12V
- Amp Draw: 18A
- Fuse Size: 30A
- Inlet Hose Diameter: 1 inch
- Outlet Hose Diameter: 1 inch
- Designed to use with fresh and seawater
- Self-priming up to 25 inches

PRODUCT NUMBER: CAE-000727-01
Recommended for the TMC Replacement Marine Macerator Pump for Electric Toilet for Boat and RV
