This TMC 12V panel switch is used to control the flush of any TMC 12V electric toilet. Operated by a 3-way rocker switch with two flush options, full flush or half flush, and a centre off position.
The switch has a built in 40amp relay circuit loop that protects the electric toilet against instant high current caused by sudden start or abnormal impeller friction.
SPECIFICATIONS:
The switch has a built in 40amp relay circuit loop that protects the electric toilet against instant high current caused by sudden start or abnormal impeller friction.
SPECIFICATIONS:
- 3-Way Rocker Switch in the Control Panel with built-in electronic control system that allows 2 flush options:
- Half Flush - Lasts for 5 Seconds and delivers 2 litres of water.
- Full Flush - Lasts for 10 seconds and delivers 4 litres of water
- Fuse Holder and boxed fuse package
- Pre-Set 30A Fuse
- Front Fascia
- Equipped with Seals for Water - Splash proof
- Relay/PCB/Seal
PRODUCT CODE: CAE-004148-01
